    Energy Saving Automatic Tube Chamfering Machine Ce Multiple Operating Modes

    Ask Lasest Price
    Brand Name : guozhong
    Model Number : Double-end beveling machine
    Certification : ce
    Price : us 10000~20000 set
    Payment Terms : T/T, D/P, D/A, L/C
    Supply Ability : 100 set month
    Delivery Time : 15day
    • Product Details
    • Company Profile

    Energy Saving Automatic Tube Chamfering Machine Ce Multiple Operating Modes

    Multiple operating modes Energy saving automatic tube chamfering machine ce
    1 Technical characteristics of double-head beveling machine
    1.1 The equipment adopts PLC control, simple structure, safe and practical.
    1.2 The control interface is operated by touch keys, which is convenient and quick.
    1.3 Processing operations are easy to learn and understand.
    1.4 The feed of the equipment uses a large torque stepper motor, which has a fast response
    speed and a large cutting force.
    1.5 The overall device is a triangular design with strong structural performance and is not easy to
    deform.
    1.6 The movement of the equipment is linear guide, and the performance is reliable.
    1.7 The upper stroke of the hydraulic tooling can be adjusted, which can be used quickly and
    improve production efficiency
    convenient for application.
    Energy Saving Automatic Tube Chamfering Machine Ce Multiple Operating Modes
    2 technical details: 1 technical details:
    Elbow Radius: 1.0D & 1.5D
    Elbow Angle: 90°
    Raw Material: Carbon Steel, Stainless Steel, Alloy Steel
    Applicable Standards: ASME B16.9, ASME B16.11, GB12459, JIS, DIN, GOST
    Parameter
    Model
    Beveling Size
    (Inch)
    Max. Wall Thickness
    Feed Type of Sliding Table
    Clamping Type
    System Pressure
    (Mpa)
    Power
    (KW)
    Dimension
    (mm)
    Weight
    (T)
    YWDJ2503A
    1/2"-3"
    SCH80
    Hydraulic
    Hydraulic
    7
    10
    1500*1500*1600
    3.6
    YWDJ3204B
    1"-4"
    SCH80
    Hydraulic
    Hydraulic
    7
    15
    1700*1700*1900
    4.2
    YWDJ3205A
    1"-5"
    SCH80
    Hydraulic
    Hydraulic
    7
    15
    1800*1800*1980
    5.5
    YWDJ3206B
    2"-6"
    SCH80
    Hydraulic
    Hydraulic
    7
    15
    2000*2000*2000
    5.6
    YWDJ4006B
    3"-6"
    SCH80
    Hydraulic
    Hydraulic
    7
    19
    2300*2300*2100
    7.4
    YWDJ4008A
    3"-8"
    SCH80
    Hydraulic
    Hydraulic
    7
    19
    2500*2500*2200
    8
    YWDJ4010B
    4"-10"
    SCH80
    Hydraulic
    Hydraulic
    7
    19
    2600*2600*2500
    8.5
    YWDJ5012B
    5"-12"
    SCH80
    Hydraulic
    Hydraulic
    7
    26
    2600*2600*2550
    12
    YWDJ5016A
    8"-16"
    SCH80
    Hydraulic
    Hydraulic
    7
    34
    3000*3000*2800
    14
    YWDJ6324A
    12"-24"
    SCH80
    Hydraulic
    Hydraulic
    7
    48
    4100*4100*3350
    25
    YWDJ8032A
    22"-32"
    SCH80
    Hydraulic
    Hydraulic
    7
    68
    4400*4400*4100
    36
    YWDJ8036A
    28"-36"
    SCH80
    Hydraulic
    Hydraulic
    7
    68
    4500*4500*4600
    40

    * It is an ideal equipment for beveling both LR & SR for 90°elbows of size 1/2" to 48" in various standards.
    * The elbow materials can be carbon steel, stainless steel and alloy steel etc.
    * There are three tips for each cutter in different angles, which can work at the same time to ensure effective cutting and save working time and develop production efficiency.
    * The application of floating cutter for large size helps to solve the difficulties of rough roundness of hydro-forming elbows, which ensures the high beveling precision and qualified ratio.
    * The machines have high precise-locating device for elbow jigs, excellent hydraulic clamping device and individual hydraulic power unit. The application of sliding tables with functions of fast feeding, inching and fast retreat enables the safety during working.
    * Thereare three kinds of operation methods: manual, semi-auto and automatic; easy operation system helps to save working time and improve production efficiency.
    * The cutting speed is hydraulic stepless speed control and the processing stroke is also adjustable in according to the size and the thickness of elbows, and the products processed by the machine are strictly complying with relevant elbow beveling standard.
    * The elbow beveling machine can bevelingor chamfering 30°,45°,60°,90° elbows with custom design.
    * Get CE approval and ISO9001:2015 certificate.
